SPO12N10T5
Capacity: 12,000 lbs. $11,098.00
You can’t find a better designed and better engineered 12,000-pound two post lift. Due to its size, the SPO12 gives techs a feeling of even greater safety when they’re under a vehicle, while also giving them a little more space between the columns. Its size and its larger footprint make it optimal for shops that have larger bays and work on taller, heavier vehicles. And that’s why it’s chosen by more dealers and independent repair shops than any other lift in its category.
- True symmetrical, single-piece “Double S” columns
- Standard front & rear three-stage arms
- Truck adapters with stackable inserts for added reach
- Available in alternate height configurations to fit your shop’s needs
- Available with Shockwave™
- ALI Gold Certified
Features
- 3 3/8” minimum adapter height
- 20% more reach than 3-stage arms with thread-up adapters
- 30% larger arm sweep than conventional 2-stage arms with flip-up adapters
- Comes standard with adjustable round, truck and stackable adapter extensions
- Available with SHOCKWAVE™
- ALI Gold Certified
The SPO12 can be configured with Rotary’s exclusive Shockwave™
technology. Rise and descend twice as fast as standard lifts.
The SPO12 can be configured with standard arms.
Specifications
| Specification | SPO12 |
| Capacity | 12,000 lbs. |
| Rise | 72 3/4” – 75 1/4” |
| Overall Height | 13′ 8″ |
| Base Required Ceiling Height | 14′ |
| FJ5160 1′ Height Extension Required Ceiling Height | 15′ |
| FJ5161 2′ Height Extension Required Ceiling Height | 16′ |
| Overall Width | 11′ 5 5/8″ |
| Drive-Thru Width | 8′ 6 3/8″ |
| Front Arm Min/Max | 27 1/2″-59″ |
| Rear Arm Min/Max | 27 1/2″-59″ |
| Min. Adapter Height | 4 3/4″ |
| Motor | 2 HP |
| Voltage | 208v-230v |
| Time of Full Rise/Decent | 60 secs./40 secs. |
| Min. Bay Size | 12’x26′ |
Disclaimer
Note: Freight charges for this product are NOT included and will be calculated when order is placed. Local sales tax rates will apply on all Rotary Lift purchases that are drop-shipped from the manufacturer. Regional customers may will-call this product at our warehouse in Lodi, California.
